BKTE 100

Floor duct telescopic insert, height = 100 mm

The floor duct telescopic insert BKTE 100 ensures full flexibility during assembly. Its length can be continuously adjusted between 150 and 650 mm allowing two floor ducts to be variably connected without requiring any cutting work. The telescopic insert is pushed into the existing channel by at least 50 mm on one side. The perforated side of the telescopic insert can be bolted together with the BKV connectors. Subsequent changes can be made to the system with very little effort. The floor duct telescopic insert is available in sendzimir hot-dip galvanised steel. The sides are 100 mm high and it is 100 to 600 mm wide. The total length is 700 mm.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

B

L

t

W

  • BKTE 100-700-10S
    Floor duct telescopic insert
    100 mm
    100 mm
    700 mm
    1.50 mm
    2.620 kg
    More information
  • BKTE 100-700-15S
    Floor duct telescopic insert
    100 mm
    150 mm
    700 mm
    1.50 mm
    3.080 kg
    More information
  • BKTE 100-700-20S
    Floor duct telescopic insert
    100 mm
    200 mm
    700 mm
    1.50 mm
    3.520 kg
    More information
  • BKTE 100-700-30S
    Floor duct telescopic insert
    100 mm
    300 mm
    700 mm
    1.50 mm
    4.460 kg
    More information
  • BKTE 100-700-40S
    Floor duct telescopic insert
    100 mm
    400 mm
    700 mm
    1.50 mm
    5.370 kg
    More information
  • BKTE 100-700-50S
    Floor duct telescopic insert
    100 mm
    500 mm
    700 mm
    1.50 mm
    6.280 kg
    More information
  • BKTE 100-700-60S
    Floor duct telescopic insert
    100 mm
    600 mm
    700 mm
    1.50 mm
    7.190 kg
    More information

Details

    Advantages

    • Continuously variable length adjustment range of 150 to 650 mm.
    • Easy to assemble
    • No cutting required

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Technical Information for Flush-Mounted Duct Systems

    Technische Information

    PDF, 6 MB

    de en

  • Floor ducts - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

BIM- and CAD-Data

  • BIM Data Toothed Anchor Channels JXA-PC

    BIM Data Toothed Anchor Channels JXA-PC

    BIM data

    ZIP, 6 MB

    de en

Included accessories
