BKS 100

Floor duct riser, height = 100 mm

The floor duct riser BKS 100 with integrated connectors allows the direction of cable routing to be changed vertically by 90° upwards and downwards. It is 100 mm high and 100 to 600 mm wide. It is made of sendzimir hot-dip galvanised steel. The floor duct riser is fitted to the floor duct to be connected using the supplied connectors and clamping screws. The floor bracket must be bent according to its function as a drop section or as a rising bend.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

height

B

width

L

length

t

material thickness

direction

Richtungsänderung

W

Winkel

G

Weight per storage unit
  • BKS 100-10S
    Floor duct riser
    100 mm
    100 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    3.623 kg
    Included accessories
    More information
  • BKS 100-15S
    Floor duct riser
    100 mm
    150 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    4.034 kg
    Included accessories
    More information
  • BKS 100-20S
    Floor duct riser
    100 mm
    200 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    4.419 kg
    Included accessories
    More information
  • BKS 100-30S
    Floor duct riser
    100 mm
    300 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    5.244 kg
    Included accessories
    More information
  • BKS 100-40S
    Floor duct riser
    100 mm
    400 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    6.044 kg
    Included accessories
    More information
  • BKS 100-50S
    Floor duct riser
    100 mm
    500 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    6.832 kg
    Included accessories
    More information
  • BKS 100-60S
    Floor duct riser
    100 mm
    600 mm
    495 mm
    2.00 mm
    rising/falling
    90°
    7.658 kg
    Included accessories
    More information

Details

  • Allows the direction of cable routing to be changed by 90°.
  • Cable-friendly guide
