BKGR 110

Floor duct with miter cut, right, height = 110 mm

The floor duct branch BKGR 110 with a mitre cut on the right and integrated connectors allows the direction of cable routing to be changed horizontally in the form of a 45° branch. It is 110 mm high and 100 to 600 mm wide. It is made of sendzimir hot-dip galvanised steel. To dissipate vertical live loads, one separating strip must be installed in the floor duct for widths ≥ 300 mm and two separating strips for widths ≥ 500 mm. The side rail of the main floor duct is cut out accordingly at the point where the connecting floor duct will branch off. The BKGR branch is positioned and bolted in place at this point. The branching floor duct can then be pushed in.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

t

material thickness

W

Angle

G

Weight per storage unit
  • BKGR 110-10S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    100 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    2.872 kg
    Included accessories
    More information
  • BKGR 110-15S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    150 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    3.242 kg
    Included accessories
    More information
  • BKGR 110-20S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    200 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    3.652 kg
    Included accessories
    More information
  • BKGR 110-30S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    300 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    4.592 kg
    Included accessories
    More information
  • BKGR 110-40S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    400 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    5.702 kg
    Included accessories
    More information
  • BKGR 110-50S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    500 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    6.982 kg
    Included accessories
    More information
  • BKGR 110-60S
    Floor duct branch with mitre cut,
    height
    110 mm
    width
    600 mm
    material thickness
    2.00 mm
    Angle
    45°
    Weight per storage unit
    8.352 kg
    Included accessories
    More information

Details

  • Changes the cable routing direction horizontally in the form of a branch of 45°.
