BKAA 110

Floor duct add-on tee, height = 110 mm

The BKAA 110 floor duct attachment branch with integrated connectors allows the direction of cable routing to be changed horizontally by 90°. It is 110 mm high and 100 to 600 mm wide. It is made of sendzimir hot-dip galvanised steel. To dissipate vertical live loads, one separating strip must be installed in the floor duct for widths ≥ 300 mm and two separating strips for widths ≥ 500 mm. The side rail of the main floor duct is cut out accordingly at the point where the connecting floor duct will branch off. The BKAA attachment branch is positioned and bolted in place at this point. The branching floor duct can then be pushed in.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

Article

H

Höhe

B

Breite

t

Materialstärke

W

Winkel

G

Gewicht je Lagermengeneinheit
  • BKAA 110-10S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    100 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    1.348 kg
    Included accessories
    More information
  • BKAA 110-15S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    150 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    1.488 kg
    Included accessories
    More information
  • BKAA 110-20S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    200 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    1.568 kg
    Included accessories
    More information
  • BKAA 110-30S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    300 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    1.788 kg
    Included accessories
    More information
  • BKAA 110-40S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    400 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    1.998 kg
    Included accessories
    More information
  • BKAA 110-50S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    500 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    2.218 kg
    Included accessories
    More information
  • BKAA 110-60S
    Bodenkanal-Anbauabzweig, T-Abzweig 90°,
    Höhe
    110 mm
    Breite
    600 mm
    Materialstärke
    2.00 mm
    Winkel
    90°
    Gewicht je Lagermengeneinheit
    2.438 kg
    Included accessories
    More information

Details

  • Changes the cable routing direction horizontally in the form of a branch of 90°.
  • Cable-friendly guide

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • BK Floor Duct - Technical Information

    Technische Information

    PDF, 6 MB

    de en

  • Floor ducts - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

BIM- and CAD-Data

  • BIM for BK floor ducts

    BIM for BK floor ducts

    BIM data

    ZIP, 6 MB

    de en

Included accessories
