BKA 110

Floor duct tee, height = 110 mm

The floor duct branch BKA 110 with integrated connectors allows the direction of cable routing to be changed horizontally by 90°. It is 110 mm high and 100 to 600 mm wide. It is made of sendzimir hot-dip galvanised steel. To dissipate vertical live loads, one separating strip must be installed in the floor duct for widths ≥ 300 mm and two separating strips for widths ≥ 500 mm. The branch is inserted between two floor ducts. The branching floor duct can then be pushed in.

Get in touch Download datasheet

Variants

Steel, pre-galvanised/Sendzimir process

Article

H

height

B

width

t

material thickness

W

Angle

G

Weight per storage unit
  • BKA 110-10S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    100 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    2.934 kg
    Included accessories
    More information
  • BKA 110-15S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    150 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    3.384 kg
    Included accessories
    More information
  • BKA 110-20S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    200 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    3.894 kg
    Included accessories
    More information
  • BKA 110-30S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    300 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    5.144 kg
    Included accessories
    More information
  • BKA 110-40S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    400 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    6.754 kg
    Included accessories
    More information
  • BKA 110-50S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    500 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    8.624 kg
    Included accessories
    More information
  • BKA 110-60S
    Floor duct branch, 90° T piece,
    height
    110 mm
    width
    600 mm
    material thickness
    2.00 mm
    Angle
    90°
    Weight per storage unit
    10.844 kg
    Included accessories
    More information

Details

  • Changes the cable routing direction horizontally in the form of a branch of 90°.
  • Cable-friendly guide

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • BK Floor Duct - Technical Information

    Technische Information

    PDF, 6 MB

    de en

  • Floor ducts - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

BIM- and CAD-Data

  • BIM for BK floor ducts

    BIM for BK floor ducts

    BIM data

    ZIP, 6 MB

    de en

Included accessories
