BKADR-RHP

Floor duct branch cover with anti-slip embossing

The floor duct branch cover BKADR-RHP is placed on top of the BKA floor duct branch and protects cables and supply lines from flying sparks and other mechanical influences. It is 100 to 600 mm wide corresponding to the branch. The floor duct branch cover is made of sendzimir hot-dip galvanised steel with slip resistance class R12. With a maximum compartment size of 200 mm, we guarantee a tested load capacity of 5.00 kN according to EN 50085-2-2. They come with pre-assembled turning bolts.

Load requirements according to: EN 50085-2-2
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

B

t

Pmax

W

Details

  • Load requirements according to: EN 50085-2-2

    • Advantages

    • Loadable up to 5 kN
    • Non-slip embossing R12
    • Easy assembly

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Technical Information for Flush-Mounted Duct Systems

    Technische Information

    PDF, 6 MB

    de en

  • Floor ducts - Assembly instructions

    Montageanleitung

    PDF, 2 MB

    de en

BIM- and CAD-Data

  • BIM Data Toothed Anchor Channels JXA-PC

    BIM Data Toothed Anchor Channels JXA-PC

    BIM data

    ZIP, 6 MB

    de en

Included accessories
