B 7

30x15 mm profile rail, unperforated

The profile rail B 7 is unperforated and consists of a C profile 30 x 15 mm with a slot width of 16 mm (material thickness = 1.5 mm). We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications. It is available in lengths of 3000 or 6000 mm.

Get in touchDownload datasheet

Variants

steel, bright

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit

  • B 7-30B
    Channel B 7-30B
    profile height
    15 mm
    profile width
    30 mm
    length
    3000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    2.220 kg
    More information
  • B 7-60B
    Channel B 7-60B
    profile height
    15 mm
    profile width
    30 mm
    length
    6000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    4.440 kg
    More information

Steel, pre-galvanised/Sendzimir process

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit

  • B 7-30S
    Channel B 7-30S
    profile height
    15 mm
    profile width
    30 mm
    length
    3000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    2.220 kg
    More information
  • B 7-60S
    Channel B 7-60S
    profile height
    15 mm
    profile width
    30 mm
    length
    6000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    4.440 kg
    More information

Steel, hot-dip galvanised

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit

  • B 7-30F
    Channel B 7-30F
    profile height
    15 mm
    profile width
    30 mm
    length
    3000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    2.500 kg
    More information
  • B 7-60F
    Channel B 7-60F
    profile height
    15 mm
    profile width
    30 mm
    length
    6000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    4.750 kg
    More information

Stainless steel, acc. to AISI 304 (BS 304S31)

Article

HP

profile height

BP

profile width

L

length

t

material thickness

G

Weight per storage unit

  • B 7-30E
    Channel B 7-30E
    profile height
    15 mm
    profile width
    30 mm
    length
    3000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    2.220 kg
    More information
  • B 7-60E
    Channel B 7-60E
    profile height
    15 mm
    profile width
    30 mm
    length
    6000 mm
    material thickness
    1.50 mm
    Weight per storage unit
    4.440 kg
    More information
