AVRS

Pipe clamp for mounting channels

The pipe clamp AVRS is used to fasten pipes in C mounting channels (A 41, KHA 41, KHAL 41) with 22 mm slot width. It has a fastening hole with Ø 14 mm and is made of hot-dip galvanised steel. Fastening accessories must be ordered separately, depending on the application.

Get in touchDownload datasheet

Variants

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

t

Materialstärke

D

Durchmesser

G

Gewicht je Lagermengeneinheit

  • AVRS 30F
    Rohrschelle
    Höhe
    27 mm
    Breite
    32 mm
    Materialstärke
    3 mm
    Durchmesser
    30 mm
    Gewicht je Lagermengeneinheit
    0.076 kg
    More information
  • AVRS 60F
    Rohrschelle
    Höhe
    57 mm
    Breite
    32 mm
    Materialstärke
    3 mm
    Durchmesser
    60 mm
    Gewicht je Lagermengeneinheit
    0.076 kg
    More information
