UKE185 V

Stainless steel hinged cover compact single outlet, 8-way, angular

UKE185 V are hinged cover compact single outlets consisting of a floor socket, a height-adjustable single outlet and a formwork body. The square components are inserted directly into the screed and are used to accommodate up to eight installation devices. In addition, M25 pipes can be routed through the perforated side walls of the floor socket. The outlets are made of stainless steel (V2A) and are suitable for use in dry-cleaned and damp-cleaned rooms with office traffic loads. They are available with installation dimensions of 190 x 264 mm.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Article

H

height

Hmin

minimum installation height

B

width

L

length

N

levelling range

Pmax

maximum load

E

fitting dimension

IPg

IP protection level in used condition

IPn

IP protection level in unused condition

G

Weight per storage unit
  • UKE185 15-V E
    Compact single outlet
    height
    19 mm
    minimum installation height
    90 mm
    width
    185 mm
    length
    258 mm
    levelling range
    35 mm
    maximum load
    2.00 kN
    fitting dimension
    190 x 264 mm
    IP protection level in used condition
    IP 20
    IP protection level in unused condition
    IP 30
    Weight per storage unit
    3.273 kg
    More information
  • UKE185 25-V E
    Compact single outlet
    height
    29 mm
    minimum installation height
    100 mm
    width
    185 mm
    length
    258 mm
    levelling range
    35 mm
    maximum load
    2.00 kN
    fitting dimension
    190 x 264 mm
    IP protection level in used condition
    IP 20
    IP protection level in unused condition
    IP 30
    Weight per storage unit
    3.646 kg
    More information

Details

  • Load requirements according to: DIN EN 50085
