UEBSQTF S

Cross beam

UEBSQTF S components are transverse cross-beams for screed-flush ducts and are used to support cover joints. The products are made of sendzimir hot-dip galvanised sheet steel in line with DIN EN 10346 and are supplied with two countersunk sheet metal bolts BSS 4.8 x 16.

Load requirements according to: DIN EN 50085
Get in touchDownload datasheet

Variants

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit

  • UEBSQTF 30S
    Quertraverse,
    Höhe
    20 mm
    Breite
    300 mm
    Länge
    61 mm
    Gewicht je Lagermengeneinheit
    0.609 kg
    Included accessories
    More information
  • UEBSQTF 40S
    Quertraverse,
    Höhe
    20 mm
    Breite
    400 mm
    Länge
    61 mm
    Gewicht je Lagermengeneinheit
    0.855 kg
    Included accessories
    More information
  • UEBSQTF 50S
    Quertraverse,
    Höhe
    20 mm
    Breite
    500 mm
    Länge
    61 mm
    Gewicht je Lagermengeneinheit
    1.102 kg
    Included accessories
    More information

Details

  • Load requirements according to: DIN EN 50085
  • VDE/TÜV approval according to DIN EN 50085
