JVB-V

Connection straps

The connection straps JVB-V are designed for connections that transmit transverse loads, e.g. for frontal column/wall connections. They are available in three different lengths and are made of either galvanised steel or stainless steel.

Variants

Article

H

height

B

width

L

length

L1

length 1

L2

length 2

G

Weight per storage unit

  • JVB-V-2815-108-GV
    JORDAHL connecting strap JVB-V
    6 mm
    50 mm
    283 mm
    10 mm
    273 mm
    0.616 kg
  • JVB-V-2815-108-L4
    JORDAHL connecting strap JVB-V
    6 mm
    50 mm
    283 mm
    10 mm
    273 mm
    0.608 kg
  • JVB-V-3817-122-GV
    JORDAHL connecting strap JVB-V
    6 mm
    75 mm
    340 mm
    12 mm
    327 mm
    1.069 kg
  • JVB-V-3817-122-L4
    JORDAHL connecting strap JVB-V
    6 mm
    75 mm
    340 mm
    12 mm
    327 mm
    1.095 kg
  • JVB-V-5030-152-GV
    JORDAHL connecting strap JVB-V
    6 mm
    100 mm
    415 mm
    22 mm
    392 mm
    1.770 kg
  • JVB-V-5030-152-L4
    JORDAHL connecting strap JVB-V
    6 mm
    100 mm
    415 mm
    22 mm
    392 mm
    1.768 kg

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list 2025 Shell construction / facade

    Valid from February 1, 2025

    PDF, 18 MB

    de en
  • Technical information Channels and Accessories

    Technical information

    PDF, 14 MB

    de en
  • Declaration of Performance Connection Straps JVB
