GTR 60

Mesh cable tray separating strip, height = 50 mm

Cables and lines with different functions or voltages can be routed separately from one another in the same mesh cable tray using the mesh cable tray separating strip GTR 60. The separating strip is mounted on the mesh cable tray with three KLU clamp fasteners: two KLU each 100 mm from the separating strip end, one KLU in the middle. The mesh cable tray separating strip GTR 60 is 50 mm high and 3000 mm long. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

H

L

W

Included accessories

  • GTR 60S
    wire-mesh cable tray barrier strip
    50 mm
    3000 mm
    1.576 kg
    Included accessories
    More information

steel, batch/hot-dip galvanized

Article

H

L

W

Included accessories

  • GTR 60F
    wire-mesh cable tray barrier strip
    50 mm
    3000 mm
    1.682 kg
    Included accessories
    More information

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

L

W

Included accessories

  • GTR 60E
    wire-mesh cable tray barrier strip
    50 mm
    3000 mm
    2.091 kg
    Included accessories
    More information

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Article

H

L

W

Included accessories

  • GTR 60E4
    wire-mesh cable tray barrier strip
    33 mm
    3000 mm
    2.116 kg
    Included accessories
    More information
