GKAB

Mesh cable tray outlet plate

The mesh cable tray outlet plate GKAB supports compliance with required bending radii in the vertical design of cables and lines. It is mounted on the mesh cable tray with two KLU clamping assemblies. The spacing of the longitudinal wires of the mesh cable tray is not important during installation, but the spacing of the cross wires should be at least 94 mm. The mesh cable tray outlet plate GKAB is made of sendzimir hot-dip galvanised steel.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

Article

H

Höhe

B

Breite

L

Länge

t

Materialstärke

R

Radius

G

Gewicht je Lagermengeneinheit
  • GKAB S
    Kabelabgangsblech
    55 mm
    94 mm
    150 mm
    1.00 mm
    45 mm
    0.179 kg
    Included accessories
    More information

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Price list Building extension 2025

    Valid from February 1st, 2025, updated version from 27/01/2025.

    PDF, 46 MB

    de en

  • Cable trays - Assembly instructions

    Montageanleitung

    PDF, 4 MB

    de en

  • Mesh cable trays - Technical information

    Technische Information

    PDF, 2 MB

    de en

  • Mesh cable trays G

    Compact overview

    PDF, 533 KB

    de
