UVABU

Plug-to-socket connecting line, WAGO

UVABU components are prefabricated connection lines. They consist of a WAGO WINSTA MIDI system connection cable with a plug with 3-pin input and output and a socket. The cables are type H05 VV-F 3G2.5 with a rated voltage/current of 250 V/20 A and a cable cross-section of 2.5 mm².

Get in touch Download datasheet

Variants

Article

Output

Input

colour

color

KQ

Cable cross-section

G

Weight per storage unit
  • UVABU-S-2.5-100
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    black
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.176 kg
    More information
  • UVABU-S-2.5-400
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    black
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.610 kg
    More information
  • UVABU-S-2.5-600
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    black
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.906 kg
    More information
  • UVABU-S-2.5-800
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    black
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    1.203 kg
    More information
  • UVABU-W-2.5-100
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    white
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.176 kg
    More information
  • UVABU-W-2.5-400
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    white
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.610 kg
    More information
  • UVABU-W-2.5-600
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    white
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    0.906 kg
    More information
  • UVABU-W-2.5-800
    Connecting line plug - socket
    Output
    3-polig
    Input
    3-polig
    color
    white
    Cable cross-section
    2.5 mm2
    Weight per storage unit
    1.203 kg
    More information
