UGWIS-FILS10A

Mounting box pre-assembled with RCCB switch, 10 A, Wieland

UGWIS-FILS10A components are pre-assembled mounting boxes with a type 6 KA, 1 p + N, 10 A/30 mA residual current circuit breaker (RCCB). The mounting boxes are connected with a 2000 to 3000 mm long connecting cable with a 4 mm² cable cross-section and a 3-pin Wieland plug. They are completed by the addition of a 3-pin Wieland device socket under the mounting box and a 2-way socket. They are made of ABS copolymer.

Get in touch Download datasheet

Variants

Article

H

B

L

connection cable

Farbe Snap-in

KQ

W

  • UGWIS-O2FILS10A-200
    device cup pre-assembled
    46 mm
    74 mm
    225 mm
    2000 mm
    weiß
    4 mm2
    1.084 kg
    More information
  • UGWIS-O2FILS10A-300
    device cup pre-assembled
    46 mm
    74 mm
    225 mm
    3000 mm
    weiß
    4 mm2
    1.344 kg
    More information
  • UGWIS-W2FILS10A-200
    device cup pre-assembled
    46 mm
    74 mm
    225 mm
    2000 mm
    schwarz
    4 mm2
    1.084 kg
    More information
  • UGWIS-W2FILS10A-300
    device cup pre-assembled
    46 mm
    74 mm
    225 mm
    3000 mm
    schwarz
    4 mm2
    1.344 kg
    More information
