UA 1

Cover plate for 1x UDAE

UA 1 components from the underfloor systems range are square cover plates with a square opening. As a system-related accessory, the one-piece plates can be snapped onto UG mounting boxes and are used to install an installation device with a suspension bracket. The installation boards are made of high-quality ABS copolymer (ABS) in graphite black (RAL 9011). They have a matt surface and an installation dimension of E 48 mm.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

Article

B

L

E

colour

W

  • UA-1-1 113
    cover plate UA-1-1 113,
    74 mm
    113 mm
    48 mm
    RAL 9011 (graphite black)
    0.016 kg
    More information

Details

  • Load requirements according to: DIN EN 50085

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link
