RIKDS

Installation cable tray crossing cover, heavy

The installation cable tray crossing covers RIKDS are suitable for RIK installation cable tray crossings and protect them from dirt and moisture. They snap into place and interlock with the side rails. If the covers are to be used outdoors, additional securing brackets to protect against wind are required. The cover is made of sendzimir hot-dip galvanised steel.

Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

B

B2

L

L2

W

  • RIKDS 05S
    Cable tray cross-piece cover RKD 10S
    56 mm
    56 mm
    164 mm
    164 mm
    0.290 kg
    More information
  • RIKDS 10S
    Cable tray cross-piece cover RKD 10S
    106 mm
    106 mm
    214 mm
    214 mm
    0.510 kg
    More information
  • RIKDS 20S
    Cable tray cross-piece cover RKD 10S
    206 mm
    206 mm
    314 mm
    314 mm
    1.130 kg
    More information
  • RIKDS 30S
    Cable tray cross-piece cover RKD 10S
    306 mm
    306 mm
    414 mm
    414 mm
    1.990 kg
    More information
  • RIKDS 10-05S
    Cable tray cross-piece cover RKD 10S
    106 mm
    56 mm
    214 mm
    164 mm
    0.380 kg
    More information
  • RIKDS 20-10S
    Cable tray cross-piece cover RKD 10S
    206 mm
    106 mm
    314 mm
    214 mm
    0.760 kg
    More information
  • RIKDS 30-20S
    Cable tray cross-piece cover RKD 10S
    306 mm
    206 mm
    414 mm
    314 mm
    1.500 kg
    More information
