DSAHFEF8 3

Wire suspension with M8 threaded end and universal closure

The wire suspension DSAHFEF8 3 with M8 threaded end and universal closure is used for suspending cable trays and mesh cable trays from ceilings. It is made of galvanised steel and is available in lengths from 1000 to 10,000 mm. The maximum load is 0.88 kN (Gripple load class 3).

Get in touch Download datasheet

Variants

Stahl, galvanisch verzinkt

DSAHFEF8 31GV
Drahtseilabhängung
Länge
1000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.104 kg
More information
DSAHFEF8 32GV
Drahtseilabhängung
Länge
2000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.142 kg
More information
DSAHFEF8 33GV
Drahtseilabhängung
Länge
3000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.180 kg
More information
DSAHFEF8 34GV
Drahtseilabhängung
Länge
4000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.218 kg
More information
DSAHFEF8 35GV
Drahtseilabhängung
Länge
5000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.257 kg
More information
DSAHFEF8 310GV
Drahtseilabhängung
Länge
10000 mm
max. Belastung
0.88 kN
Gewicht je Lagermengeneinheit
0.415 kg
More information

Tender texts

Ausschreiben.de

Tender texts for this product

Open Link

Heinze.de

Tender texts for this product

Open Link

Downloads

**Price list 2025 Building extension**
Valid from February 1st, 2025, updated version from 31/03/2025.
de
en

BIM- und CAD-Data

BIM Data Cablele Support System Fastening Accessories (Revit)

BIM Data

Included accessories
