WPR 150 Wide-span cable tray, height = 150 mm

The wide-span cable trays WPR 150 have rails 150 mm high and are available in widths of 200 to 600 mm. The standard length is 6000 mm. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.

data sheet

Tender text

You can find the appropriate tender text for this product on these portals:

Request a callback now

Products

steel, continously hot galvanized/Sendzimir process

Products	H height	B width	L length	t material thickness	A cross section area	Q_SK distributed load control cable	weight
WPR 150-20S	150 mm	200 mm	6000 mm	1,75 mm	256 cm²	0,38 kN/m	45,130 kg
WPR 150-30S	150 mm	300 mm	6000 mm	1,75 mm	384 cm²	0,58 kN/m	50,810 kg
WPR 150-40S	150 mm	400 mm	6000 mm	1,75 mm	512 cm²	0,77 kN/m	56,680 kg
WPR 150-50S	150 mm	500 mm	6000 mm	1,75 mm	640 cm²	0,96 kN/m	62,550 kg
WPR 150-60S	150 mm	600 mm	6000 mm	1,75 mm	768 cm²	1,15 kN/m	68,410 kg

steel, batch/hot-dip galvanized

Products	H height	B width	L length	t material thickness	A cross section area	Q_SK distributed load control cable	weight
WPR 150-20F	150 mm	200 mm	6000 mm	1,75 mm	256 cm²	0,38 kN/m	48,280 kg
WPR 150-30F	150 mm	300 mm	6000 mm	1,75 mm	384 cm²	0,58 kN/m	54,360 kg
WPR 150-40F	150 mm	400 mm	6000 mm	1,75 mm	512 cm²	0,77 kN/m	60,640 kg
WPR 150-50F	150 mm	500 mm	6000 mm	1,75 mm	640 cm²	0,96 kN/m	66,920 kg
WPR 150-60F	150 mm	600 mm	6000 mm	1,75 mm	768 cm²	1,15 kN/m	73,200 kg

Stainless steel, according to ASTM 304 / BS 304 S 3

Products	H height	B width	L length	t material thickness	A cross section area	Q_SK distributed load control cable	weight
WPR 150-20E	150 mm	200 mm	6000 mm	1,75 mm	256 cm²	0,38 kN/m	48,800 kg
WPR 150-30E	150 mm	300 mm	6000 mm	1,75 mm	384 cm²	0,58 kN/m	55,680 kg
WPR 150-40E	150 mm	400 mm	6000 mm	1,75 mm	512 cm²	0,77 kN/m	62,800 kg
WPR 150-50E	150 mm	500 mm	6000 mm	1,75 mm	640 cm²	0,96 kN/m	69,920 kg
WPR 150-60E	150 mm	600 mm	6000 mm	1,75 mm	768 cm²	1,15 kN/m	77,020 kg

Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11

Products	H height	B width	L length	t material thickness	A cross section area	Q_SK distributed load control cable	weight
WPR 150-20E4	150 mm	200 mm	6000 mm	1,75 mm	256 cm²	0,38 kN/m	49,420 kg
WPR 150-30E4	150 mm	300 mm	6000 mm	1,75 mm	384 cm²	0,58 kN/m	56,400 kg
WPR 150-40E4	150 mm	400 mm	6000 mm	1,75 mm	512 cm²	0,77 kN/m	63,600 kg
WPR 150-50E4	150 mm	500 mm	6000 mm	1,75 mm	640 cm²	0,96 kN/m	70,800 kg
WPR 150-60E4	150 mm	600 mm	6000 mm	1,75 mm	768 cm²	1,15 kN/m	78,000 kg

Load Diagram

Detail and application images

Accessories

WPRB 150

Wide-span cable tray bend, height = 150 mm

WPREAB 150

Wide-span cable tray attachment corner element

WPEA 150

Wide-span attachment corner element

WPRA 150

Wide-span cable tray branch, height = 150 mm

WPRAA 150

Wide-span cable tray attachment branch, height = 150 mm

WPRK 150

Wide-span cable tray crossing, height = 150 mm

WPV 150

Wide-span cable tray connector, height = 145 mm

WPVH 150

Wide-span cable tray connector, horizontal, height = 135 mm

WPVV 150

Wide-span cable tray connector, vertical, height = 150 mm

Floor connector

WPTR 150

Wide-span cable tray separating strip, height = 100 mm

WPHS-A

Wide-span rail support (profile rail)

WPHS-K

Wide-span rail support (bracket)

WPHS-P

Wide-span rail support (profile)

WPHS-IS

Isolation strip

WPREB

Wide-span cable tray end plate

WPRKAB

Wide-span cable tray drop-out plate

Cable clamp for fastening to C profile rails
