STUS 50

Rung

The rungs STUS 50 can also be attached to the vertical ladder afterwards. They can be bolted to the side rails from the inside using BL 6 corner angles. They are suitable for STU 50-3E vertical ladders and are 200 to 1200 mm wide corresponding to the vertical ladder width. They are made of stainless steel. It is not possible to install additional STUS rungs for the vertical ladder variant with SNA nail anchors.

Get in touch Download datasheet

Variants

Stainless steel, according to ASTM 304 / BS 304 S 3

Article

H

B

L

W

Included accessories

  • STUS 50-02E
    Rung STUS 02E
    22 mm
    200 mm
    40 mm
    0.383 kg
    Included accessories
    More information
  • STUS 50-03E
    Rung STUS 03E
    22 mm
    300 mm
    40 mm
    0.489 kg
    Included accessories
    More information
  • STUS 50-04E
    Rung STUS 04E
    22 mm
    400 mm
    40 mm
    0.606 kg
    Included accessories
    More information
  • STUS 50-05E
    Rung STUS 05E
    22 mm
    500 mm
    40 mm
    0.724 kg
    Included accessories
    More information
  • STUS 50-06E
    Rung STUS 06E
    22 mm
    600 mm
    40 mm
    0.841 kg
    Included accessories
    More information
  • STUS 50-07E
    Rung STUS 07E
    22 mm
    700 mm
    40 mm
    0.958 kg
    Included accessories
    More information
  • STUS 50-08E
    Rung STUS 08E
    22 mm
    800 mm
    40 mm
    1.076 kg
    Included accessories
    More information
  • STUS 50-09E
    Rung STUS 09E
    22 mm
    900 mm
    40 mm
    1.193 kg
    Included accessories
    More information
  • STUS 50-10E
    Rung STUS 10E
    22 mm
    1000 mm
    40 mm
    1.310 kg
    Included accessories
    More information
  • STUS 50-11E
    Rung STUS 11E
    22 mm
    1100 mm
    40 mm
    1.428 kg
    Included accessories
    More information
  • STUS 50-12E
    Rung STUS 12E
    22 mm
    1200 mm
    40 mm
    1.545 kg
    Included accessories
    More information
