STLS

Rung

The rungs STLS can be installed during the installation of the vertical ladder and bolted to the side rail. They are suitable for STU 50 vertical ladders and are 203 to 793 mm wide corresponding to the vertical ladder width. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

Get in touch Download datasheet

Variants

Stahl, band-/sendzimirverzinkt

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit
  • STLS 02S
    Sprosse
    Höhe
    22 mm
    Breite
    203 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.237 kg
    Included accessories
    More information
  • STLS 03S
    Sprosse
    Höhe
    22 mm
    Breite
    293 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.355 kg
    Included accessories
    More information
  • STLS 04S
    Sprosse
    Höhe
    22 mm
    Breite
    393 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.468 kg
    Included accessories
    More information
  • STLS 05S
    Sprosse
    Höhe
    22 mm
    Breite
    493 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.577 kg
    Included accessories
    More information
  • STLS 06S
    Sprosse
    Höhe
    22 mm
    Breite
    593 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.704 kg
    Included accessories
    More information
  • STLS 07S
    Sprosse
    Höhe
    22 mm
    Breite
    693 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.894 kg
    Included accessories
    More information
  • STLS 08S
    Sprosse
    Höhe
    22 mm
    Breite
    793 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.903 kg
    Included accessories
    More information

Stahl, stück-/tauchfeuerverzinkt

Article

H

Höhe

B

Breite

L

Länge

G

Gewicht je Lagermengeneinheit
  • STLS 02F
    Sprosse
    Höhe
    22 mm
    Breite
    203 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.270 kg
    Included accessories
    More information
  • STLS 03F
    Sprosse
    Höhe
    22 mm
    Breite
    293 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.379 kg
    Included accessories
    More information
  • STLS 04F
    Sprosse
    Höhe
    22 mm
    Breite
    393 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.509 kg
    Included accessories
    More information
  • STLS 05F
    Sprosse
    Höhe
    22 mm
    Breite
    493 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.656 kg
    Included accessories
    More information
  • STLS 06F
    Sprosse
    Höhe
    22 mm
    Breite
    593 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.754 kg
    Included accessories
    More information
  • STLS 07F
    Sprosse
    Höhe
    22 mm
    Breite
    693 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    0.996 kg
    Included accessories
    More information
  • STLS 08F
    Sprosse
    Höhe
    22 mm
    Breite
    793 mm
    Länge
    40 mm
    Gewicht je Lagermengeneinheit
    1.116 kg
    Included accessories
    More information
