UV components are distribution boxes from the WAGO WINSTA MIDI system. The underfloor distributors are wired on a three-phase circuit and can be equipped with self-locking quick-assembly connectors and locking latches for connecting plug or socket parts. They are made of polyamide. The rated voltage/current corresponds to 250/400 V up to 16/25 A.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Products
| Products | H height | B width | L length | colour color | W Weight per storage unit | bookmark | ||
|---|---|---|---|---|---|---|---|---|
| UV-S0 6K | 30 mm | 145 mm | 190 mm | 6x3-polig | 1x Klemme | black | 0,446 kg | |
| UV-S 6K | 30 mm | 145 mm | 190 mm | 6x3-polig | 2x5-polig | black | 0,474 kg | |
| UV-W0 6K | 30 mm | 145 mm | 190 mm | 6x3-polig | 1x Klemme | white | 0,446 kg | |
| UV-W 6K | 30 mm | 145 mm | 190 mm | 6x3-polig | 2x5-polig | white | 0,468 kg |
