The clamping fastener WLKLT is an accessory part for the WLHS wide-span side rail support if it is used to secure the position of a WL or WLR 200 wide-span tray on steel beams. It is made of hot-dip galvanised steel.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Products
steel, batch/hot-dip galvanized
| Products | H height | B width | L length | k clamping range | SW wrench size | M torque | weight | bookmark |
|---|---|---|---|---|---|---|---|---|
| WLKLT F | 45 mm | 64 mm | 30 mm | 3 - 25 mm | 10 mm | 4,0 Nm | 0,137 kg |
