Channel nuts AM 22 are threaded plates used with mounting channels A 41, KHA 41 and KHAL 41. The threaded hole is centred by turning the nut 90° after inserting or tipping in the nut. Channel nuts, also known as locking plates, are primarily used for spaced mounting in conjunction with long bolts or threaded rods. They are available with M6, M8, M10 and M12 threads. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Products
steel, galvanic zinc plated
| Products | t material thickness | Ø thread diameter | W Weight per storage unit | bookmark |
|---|---|---|---|---|
| AM22 M6 | 6,00 mm | 6 mm | 0,026 kg | |
| AM22 M8 | 6,00 mm | 8 mm | 0,025 kg | |
| AM22 M10 | 8,00 mm | 10 mm | 0,031 kg | |
| AM22 M12 | 9,50 mm | 12 mm | 0,033 kg |
steel, batch/hot-dip galvanized
| Products | t material thickness | Ø thread diameter | W Weight per storage unit | bookmark |
|---|---|---|---|---|
| AM22 M6F | 6,00 mm | 6 mm | 0,027 kg | |
| AM22 M8F | 6,00 mm | 8 mm | 0,025 kg | |
| AM22 M10F | 8,00 mm | 10 mm | 0,039 kg | |
| AM22 M12F | 9,00 mm | 12 mm | 0,038 kg |
Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11
| Products | t material thickness | Ø thread diameter | W Weight per storage unit | bookmark |
|---|---|---|---|---|
| AM22 M6E4 | 6,00 mm | 6 mm | 0,027 kg | |
| AM22 M8E4 | 6,00 mm | 8 mm | 0,029 kg | |
| AM22 M10E4 | 8,00 mm | 10 mm | 0,035 kg | |
| AM22 M12E4 | 9,50 mm | 12 mm | 0,035 kg |
