LGKAB Cable ladder drop-out plate

The cable ladder drop-out plate LGKAB is used to route cables vertically out of the cable ladder and to protect the cables. It is 140 to 540 mm wide corresponding to the cable ladder. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

data sheet

Tender text

You can find the appropriate tender text for this product on these portals:

Request a callback now

Products

steel, continously hot galvanized/Sendzimir process

Products	height	width	length	t material thickness	radius	W Weight per storage unit
LGKAB 20S	110 mm	140 mm	129 mm	1,50 mm	100 mm	0,372 kg
LGKAB 30S	110 mm	240 mm	129 mm	1,50 mm	100 mm	0,613 kg
LGKAB 40S	110 mm	340 mm	129 mm	1,50 mm	100 mm	0,854 kg
LGKAB 50S	110 mm	440 mm	129 mm	1,50 mm	100 mm	1,112 kg
LGKAB 60S	110 mm	540 mm	129 mm	1,50 mm	100 mm	1,353 kg

steel, batch/hot-dip galvanized

Products	height	width	length	t material thickness	radius	W Weight per storage unit
LGKAB 20F	110 mm	140 mm	129 mm	1,50 mm	100 mm	0,393 kg
LGKAB 30F	110 mm	240 mm	129 mm	1,50 mm	100 mm	0,651 kg
LGKAB 40F	110 mm	340 mm	129 mm	1,50 mm	100 mm	0,909 kg
LGKAB 50F	110 mm	440 mm	129 mm	1,50 mm	100 mm	1,183 kg
LGKAB 60F	110 mm	540 mm	129 mm	1,50 mm	100 mm	1,440 kg

Stainless steel, according to ASTM 304 / BS 304 S 3

Products	height	width	length	t material thickness	radius	W Weight per storage unit
LGKAB 20E	110 mm	140 mm	129 mm	1,50 mm	100 mm	0,372 kg
LGKAB 30E	110 mm	240 mm	129 mm	1,50 mm	100 mm	0,614 kg
LGKAB 40E	110 mm	340 mm	129 mm	1,50 mm	100 mm	0,857 kg
LGKAB 50E	110 mm	440 mm	129 mm	1,50 mm	100 mm	1,116 kg
LGKAB 60E	110 mm	540 mm	129 mm	1,50 mm	100 mm	1,358 kg
