LGIB 60

Cable ladder internal bend, height = 60 mm

The cable ladder internal bend LGIB 60 allows the direction of cable routing to be changed horizontally by 90°. They are suitable for cable ladders with rails 60 mm high and are 200 to 600 mm wide. The bend is mounted on the cable ladders using LGV side connectors (please order separately). The inner radius of the LGIB cable ladder internal bend is 400 mm and is smaller than that of the LGAB cable ladder external bend. The cable ladder can thus be guided more tightly around curves depending on the circumstances. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.

The magnetic shielding attenuation is 11 dB without the cover and 20 dB with the cover.

Get in touch Download datasheet

Variants

Steel, hot-dip galvanised

LGIB 60-20F
Cable ladder inside bend LGIB 60-20F
height
60 mm
Height
60 mm
width
200 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.000 kg
More information
LGIB 60-30F
Cable ladder inside bend LGIB 60-30F
height
60 mm
Height
60 mm
width
300 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.470 kg
More information
LGIB 60-40F
Cable ladder inside bend LGIB 60-40F
height
60 mm
Height
60 mm
width
400 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.950 kg
More information
LGIB 60-50F
Cable ladder inside bend LGIB 60-50F
height
60 mm
Height
60 mm
width
500 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
5.160 kg
More information
LGIB 60-60F
Cable ladder inside bend LGIB 60-60F
height
60 mm
Height
60 mm
width
600 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
5.780 kg
More information

Stainless steel, acc. to AISI 304 (BS 304S31)

LGIB 60-20E
Cable ladder inside bend LGIB 60-20E
height
60 mm
Height
60 mm
width
200 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
2.820 kg
More information
LGIB 60-30E
Cable ladder inside bend LGIB 60-30E
height
60 mm
Height
60 mm
width
300 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.270 kg
More information
LGIB 60-40E
Cable ladder inside bend LGIB 60-40E
height
60 mm
Height
60 mm
width
400 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
3.720 kg
More information
LGIB 60-50E
Cable ladder inside bend LGIB 60-50E
height
60 mm
Height
60 mm
width
500 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
4.850 kg
More information
LGIB 60-60E
Cable ladder inside bend LGIB 60-60E
height
60 mm
Height
60 mm
width
600 mm
radius
400 mm
Direction change
horizontal
Angle
90°
Weight per storage unit
5.440 kg
More information

Details

Creates horizontal changes of the cable routing direction by 90°.
