UBSFMD4 R

Mounting cover, for round parts

The UBSFMD4 R component is an assembly cover for round parts within the screed-flush duct system UBSF. It is made of hot-dip galvanised sheet steel, has a length of 500 mm and is available in widths of 200 to 600 mm. The component complies with DIN EN 50085 - the European standard for electrical installation duct systems, and is tested and certified by VDE.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

B

L

t

E

W

  • UBSFMD4-122R 20S
    Mounting Cover, round
    200 mm
    500 mm
    4 mm
    122 mm
    2.705 kg
    More information
  • UBSFMD4-122R 30S
    Mounting Cover, round
    300 mm
    500 mm
    4 mm
    122 mm
    4.274 kg
    More information
  • UBSFMD4-122R 40S
    Mounting Cover, round
    400 mm
    500 mm
    4 mm
    122 mm
    5.842 kg
    More information
  • UBSFMD4-260R 40S
    Mounting Cover, round
    400 mm
    500 mm
    4 mm
    260 mm
    4.542 kg
    More information
  • UBSFMD4-307R 40S
    Mounting Cover, round
    400 mm
    500 mm
    4 mm
    307 mm
    3.885 kg
    More information
  • UBSFMD4-307R 50S
    Mounting Cover, round
    500 mm
    500 mm
    4 mm
    307 mm
    5.453 kg
    More information
  • UBSFMD4-307R 60S
    Mounting Cover, round
    600 mm
    500 mm
    4 mm
    307 mm
    7.022 kg
    More information

Details

  • Load requirements according to: DIN EN 50085

Tender texts

Ausschreiben.de

Tender text for this product

Open Link
Heinze.de

Tender text for this product

Open Link

Downloads

  • Screed-flush duct UBSF

    Technische Information

    PDF, 3 MB

    de en

  • Screed-flush duct UBSF

    Montageanleitung

    PDF, 1 MB

    de en

Included accessories
