UBSF

Screed-flush duct system, free-standing

The screed-flush duct system UBSF is used for horizontal cable routing and is a free-standing, open system with removable covers. It is made of hot-dip galvanised sheet steel and consists of pre-assembled side sections, levelling brackets and crossbeams including accessories. The duct is installed in the concrete ceiling and is designed for traffic loads in offices. UBSF has a length of 2000 mm and is available in widths between 200 and 600 mm. The minimum installation height varies between 60 mm and 150 mm, depending on the product. The duct is suitable for rooms with dry and wet-cleaned floors. The screed-flush duct system UBSF complies with DIN EN 50085 - the European standard for electrical installation duct systems, and is tested and certified by VDE.

Load requirements according to: DIN EN 50085
Get in touch Download datasheet

Variants

steel, continously hot galvanized/Sendzimir process

Article

Hmin

B

L

N

Pmax

W

  • UBSF 100-20S
    duct bottom piece UBK 100-20S, L=3000mm,
    100 mm
    200 mm
    2000 mm
    55 mm
    3 kN
    9.948 kg
    More information
  • UBSF 100-30S
    duct bottom piece UBK 100-20S, L=3000mm,
    100 mm
    300 mm
    2000 mm
    55 mm
    3 kN
    11.326 kg
    More information
  • UBSF 100-40S
    duct bottom piece UBK 100-20S, L=3000mm,
    100 mm
    400 mm
    2000 mm
    55 mm
    3 kN
    13.020 kg
    More information
  • UBSF 100-50S
    duct bottom piece UBK 100-20S, L=3000mm,
    100 mm
    500 mm
    2000 mm
    55 mm
    3 kN
    14.080 kg
    More information
  • UBSF 100-60S
    duct bottom piece UBK 100-20S, L=3000mm,
    100 mm
    600 mm
    2000 mm
    55 mm
    3 kN
    14.926 kg
    More information
  • UBSF 150-20S
    duct bottom piece UBK 100-20S, L=3000mm,
    150 mm
    200 mm
    2000 mm
    105 mm
    3 kN
    13.928 kg
    More information
  • UBSF 150-30S
    duct bottom piece UBK 100-20S, L=3000mm,
    150 mm
    300 mm
    2000 mm
    105 mm
    3 kN
    15.302 kg
    More information
  • UBSF 150-40S
    duct bottom piece UBK 100-20S, L=3000mm,
    150 mm
    400 mm
    2000 mm
    105 mm
    3 kN
    16.762 kg
    More information
  • UBSF 150-50S
    duct bottom piece UBK 100-20S, L=3000mm,
    150 mm
    500 mm
    2000 mm
    105 mm
    3 kN
    17.822 kg
    More information
  • UBSF 150-60S
    duct bottom piece UBK 100-20S, L=3000mm,
    150 mm
    600 mm
    2000 mm
    105 mm
    3 kN
    18.842 kg
    More information
  • UBSF 60-20S
    duct bottom piece UBK 100-20S, L=3000mm,
    60 mm
    200 mm
    2000 mm
    20 mm
    3 kN
    6.638 kg
    More information
  • UBSF 60-30S
    duct bottom piece UBK 100-20S, L=3000mm,
    60 mm
    300 mm
    2000 mm
    20 mm
    3 kN
    8.016 kg
    More information
  • UBSF 60-40S
    duct bottom piece UBK 100-20S, L=3000mm,
    60 mm
    400 mm
    2000 mm
    20 mm
    3 kN
    9.514 kg
    More information
  • UBSF 60-50S
    duct bottom piece UBK 100-20S, L=3000mm,
    60 mm
    500 mm
    2000 mm
    20 mm
    3 kN
    10.570 kg
    More information
  • UBSF 60-60S
    duct bottom piece UBK 100-20S, L=3000mm,
    60 mm
    600 mm
    2000 mm
    20 mm
    3 kN
    11.630 kg
    More information
  • UBSF 75-20S
    duct bottom piece UBK 100-20S, L=3000mm,
    75 mm
    200 mm
    2000 mm
    30 mm
    3 kN
    8.472 kg
    More information
  • UBSF 75-30S
    duct bottom piece UBK 100-20S, L=3000mm,
    75 mm
    300 mm
    2000 mm
    30 mm
    3 kN
    9.850 kg
    More information
  • UBSF 75-40S
    duct bottom piece UBK 100-20S, L=3000mm,
    75 mm
    400 mm
    2000 mm
    30 mm
    3 kN
    11.198 kg
    More information
  • UBSF 75-50S
    duct bottom piece UBK 100-20S, L=3000mm,
    75 mm
    500 mm
    2000 mm
    30 mm
    3 kN
    12.258 kg
    More information
  • UBSF 75-60S
    duct bottom piece UBK 100-20S, L=3000mm,
    75 mm
    600 mm
    2000 mm
    30 mm
    3 kN
    13.314 kg
    More information

Details

  • Load requirements according to: DIN EN 50085
