UNE 305R components are round dummy covers. These height-adjustable covers are protective covers for cartridge installation units with a maximum of three mounting boxes in UBDHB floor sockets and raised or false floor openings. The units are suitable for dry-cleaned rooms with office traffic loads. The products from the underfloor systems range are made of sendzimir hot-dip galvanised sheet steel 4 mm thick and have a max. load capacity of 2 kN. The dummy covers have installation dimensions of 307 mm and a minimum installation height of 90 mm.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Load requirements according to: DIN EN 50085
Approvals and Certificates
Approvals and Certificates
- VDE/TÜV approval according to DIN EN 50085
Products
| Products | Hmin minimum installation height | N levelling range | t material thickness | Pmax maximum load | E fitting dimension | W Weight per storage unit | bookmark |
|---|---|---|---|---|---|---|---|
| UNE 305R-90S | 90 mm | 55 mm | 4,00 mm | 2,00 kN | 307 mm | 3,305 kg |
