Varianten
Stahl, band-/sendzimirverzinkt
Artikel
HP
BP
L
t
G
-
KHA 7-02S
Profilschiene gelocht 40/22X1,522 mm39.5 mm200 mm1.50 mm0.210 kg -
KHA 7-03S
Profilschiene gelocht 40/22X1,522 mm39.5 mm300 mm1.50 mm0.310 kg -
KHA 7-04S
Profilschiene gelocht 40/22X1,522 mm39.5 mm400 mm1.50 mm0.410 kg -
KHA 7-05S
Profilschiene gelocht 40/22X1,522 mm39.5 mm500 mm1.50 mm0.510 kg -
KHA 7-06S
Profilschiene gelocht 40/22X1,522 mm39.5 mm600 mm1.50 mm0.610 kg -
KHA 7-07S
Profilschiene gelocht 40/22X1,522 mm39.5 mm700 mm1.50 mm0.780 kg -
KHA 7-08S
Profilschiene gelocht 40/22X1,522 mm39.5 mm800 mm1.50 mm0.834 kg -
KHA 7-09S
Profilschiene gelocht 40/22X1,522 mm39.5 mm900 mm1.50 mm1.000 kg -
KHA 7-10S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1000 mm1.50 mm1.050 kg -
KHA 7-11S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1100 mm1.50 mm1.150 kg -
KHA 7-12S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1200 mm1.50 mm1.260 kg -
KHA 7-13S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1300 mm1.50 mm1.360 kg -
KHA 7-14S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1400 mm1.50 mm1.470 kg -
KHA 7-15S
Profilschiene gelocht 40/22X1,522 mm39.5 mm1500 mm1.50 mm1.570 kg -
KHA 7-20S
Profilschiene gelocht 40/22X1,522 mm39.5 mm2000 mm1.50 mm2.200 kg -
KHA 7-30S
Profilschiene gelocht 40/22X1,522 mm39.5 mm3000 mm1.50 mm3.200 kg -
KHA 7-60S
Profilschiene gelocht 40/22X1,522 mm39.5 mm6000 mm1.50 mm6.300 kg
