BGU 57 screwed head plate, KHU 57

Head plate for ceiling mounting of bracket support KHU 57

galvanized, according to DIN EN ISO 19598 / DIN EN ISO 2081

	height	width	length	t material thickness	weight
BGU 57GV	100 mm	40 mm	160 mm	5,00 mm	0,51 kg

Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)

	height	width	length	t material thickness	weight
BGU 57F	100 mm	40 mm	160 mm	5,00 mm	0,54 kg

Stainless steel, according to ASTM 304 / BS 304 S 3

	height	width	length	t material thickness	weight
BGU 57E	100 mm	40 mm	160 mm	5,00 mm	0,52 kg

Stainless steel, according to ASTM 31 Ti / AISI 316 L, BS 320S17 / BS 316S11

	height	width	length	t material thickness	weight
BGU 57E4	100 mm	40 mm	160 mm	5,00 mm	0,52 kg
