UVB 2 components are two-section vertical bends with a separating strip. They are used for the installation of screed-covered duct systems. They are manufactured as a closed rectangular profile with a 90° angle and are mounted on the raw slab with the multi-channel duct sections. The bends are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346. The upper and lower parts are permanently connected together at the factory. UVB 2 components have a VDE/TÜV approval according to DIN EN 50085.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
![Load requirements according to](/typo3conf/ext/phc_crossbase_products/Resources/Public/Images/GRA/ZER/ICO/GRA_ZER_ICO_DIN_%23SALL_%23AING_%23V1.png)
Approvals and Certificates
Approvals and Certificates
- VDE/TÜV approval according to DIN EN 50085
Products
steel, continously hot galvanized/Sendzimir process
Products | H height | B width | L length | W Weight per storage unit | bookmark | ||||
---|---|---|---|---|---|---|---|---|---|
UVB 2-28-190S | 29 mm | 186 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,709 kg | |
UVB 2-28-250S | 29 mm | 246 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,867 kg | |
UVB 2-28-350S | 29 mm | 346 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 1,132 kg | |
UVB 2-38-190S | 39 mm | 186 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,720 kg | |
UVB 2-38-250S | 39 mm | 246 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,871 kg | |
UVB 2-38-350S | 39 mm | 346 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 1,123 kg | |
UVB 2-48-190S | 49 mm | 186 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,738 kg | |
UVB 2-48-250S | 49 mm | 246 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 0,881 kg | |
UVB 2-48-350S | 49 mm | 346 mm | 132 mm | 90 ° | 0 | 1 | VERTIKAL | 1,120 kg |
