UEBDS R E Stainless steel heavy-duty dummy cover unit, 3x, round

UEBDS R E installation units are round dummy cover units with abutting edges. They can accommodate a maximum of three mounting boxes. They consist of height-adjustable mounting frames with a dummy heavy-duty cartridge, a rubber seal and the UGEAR-ELS earthing bracket. The components are suitable for use in wet-cleaned rooms with high traffic loads and are installed in assembly covers, UBDHB floor sockets and raised or false floor openings. They are made of stainless steel V2A. They have an IP protection level of IP 54 in an unused condition, a max. load capacity of 20 kN, an adjustment range of 55 mm, a min. installation height of 117 mm and installation dimensions of 307 mm.

data sheet

Tender text

You can find the appropriate tender text for this product on these portals:

Approvals and Certificates

Approvals and Certificates

  • VDE/TÜV approval according to DIN EN 50085
  • With inspection stamp dia. 130 mm: 20 kN

Products

Products H height Hmin minimum installation height N levelling range B width Pmax maximum load ØB Installation diameter mounting box maximum number of installable device casings E fitting dimension IPn IP protection level in unused condition T Depth of flooring recess W Weight per storage unit incl. show all inclusive accessoiresbookmark
UEBDS 35-R6 E38 mm117 mm55 mm305 mm20,00 kN305 mm3307 mmIP 5424 mm7,161 kg

Detail and application images
