The wide-span bend cover WPBD is suitable for WPLB and WPRB wide-span bends and protects them from dirt, moisture and UV radiation. It is placed on top of the bend and secured with WPFDK or WPFDKA formed part cover clips. The latter are used if the cover is elevated. This improves the ventilation of the cables. The cover has a radius of 450 mm corresponding to the bend. We provide components in various materials and surface finishes to ensure that various corrosion protection requirements for different areas of application are met.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Advantages
Advantages
- Protects the wide-span bend from external influences
- Easy assembly
Products
steel, continously hot galvanized/Sendzimir process
| Products | B width | R radius | W Weight per storage unit | bookmark | ||
|---|---|---|---|---|---|---|
| WPBD 20S | 251 mm | 450 mm | horizontal | 90° | 2,090 kg | |
| WPBD 30S | 351 mm | 450 mm | horizontal | 90° | 4,070 kg | |
| WPBD 40S | 451 mm | 450 mm | horizontal | 90° | 5,500 kg | |
| WPBD 50S | 551 mm | 450 mm | horizontal | 90° | 8,790 kg | |
| WPBD 60S | 651 mm | 450 mm | horizontal | 90° | 10,860 kg |
steel, batch/hot-dip galvanized
| Products | B width | R radius | W Weight per storage unit | bookmark | ||
|---|---|---|---|---|---|---|
| WPBD 20F | 251 mm | 450 mm | horizontal | 90° | 2,240 kg | |
| WPBD 30F | 351 mm | 450 mm | horizontal | 90° | 4,360 kg | |
| WPBD 40F | 451 mm | 450 mm | horizontal | 90° | 5,880 kg | |
| WPBD 50F | 551 mm | 450 mm | horizontal | 90° | 9,400 kg | |
| WPBD 60F | 651 mm | 450 mm | horizontal | 90° | 11,620 kg |
Stainless steel, according to ASTM 304 / BS 304 S 3
| Products | B width | R radius | W Weight per storage unit | bookmark | ||
|---|---|---|---|---|---|---|
| WPBD 20E | 251 mm | 450 mm | horizontal | 90° | 2,090 kg | |
| WPBD 30E | 351 mm | 450 mm | horizontal | 90° | 4,070 kg | |
| WPBD 40E | 451 mm | 450 mm | horizontal | 90° | 5,500 kg | |
| WPBD 50E | 551 mm | 450 mm | horizontal | 90° | 8,840 kg | |
| WPBD 60E | 651 mm | 450 mm | horizontal | 90° | 10,860 kg |
