UBKPRV components are connectors for screed-flush heavy-duty ducts. They are used to bolt the side profiles together at the joints. The articles are made of sendzimir hot-dip galvanised sheet steel in accordance with DIN EN 10346. They are 150 mm long, 35 mm high and are made of material 3 mm thick.

data sheet

Tender text

You can find the appropriate tender text for this product on these portals:

Products

Products H height L length t material thickness W Weight per storage unit bookmark
UBKPRV35 mm150 mm3,00 mm0,124 kg

Detail and application images
