UEBDD V E products are square dummy cover cartridges for accommodating up to three mounting boxes. The installation units consist of a carpet protection frame with dummy insert cartridge, rubber seal, opening lever and universal claw set. They are designed for damp-cleaned and dry-cleaned floor coverings with office traffic loads and are used in UBDHB floor sockets, assembly covers and raised or false floor openings. The dummy cover cartridges are made of stainless steel V2A and have an IP protection class of IP 30 in an unused condition. They have a min. installation height of 90 or 100 mm, an installation dimension of 261 x 261 mm and a max. load limit of 2 kN.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
dry maintained
moistly maintained
Load requirements according to: DIN EN 50085
Approvals and Certificates
Approvals and Certificates
- VDE/TÜV approval according to DIN EN 50085
- With inspection stamp dia. 13/130 mm: 2/3 kN
Products
| Products | H height | Hmin minimum installation height | B width | L length | E fitting dimension | Pmax maximum load | IPn IP protection level in unused condition | T Depth of flooring recess | mounting box maximum number of installable device casings | weight | incl. show all inclusive accessoires | bookmark |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| UEBDD 15-V E | 72 mm | 90 mm | 283 mm | 283 mm | 261 x 261 mm | 2,00 kN | IP-30 | 12,5 mm | 3 | 1,886 kg | ||
| UEBDD 25-V E | 82 mm | 100 mm | 283 mm | 283 mm | 261 x 261 mm | 2,00 kN | IP-30 | 22,5 mm | 3 | 2,000 kg |
