The mounting channel JML K 38/17 has environmental product declaration EPD-JDL-20200260-IBB1-DE and is made of hot-dip galvanised steel (fv), stainless steel (A4) or rolled plain steel (wb). It has a static load-bearing capacity of the normal force (NRd) of 9.8 kN. The mounting channel is available in lengths of 100 to 6000 mm and is paired with the bolts JH M10 - JH M16. The profile is 38 mm wide and 17 mm high.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
: EPD-JDL-20200260-IBB1-DE
Approvals and Certificates
Approvals and Certificates
- Environmental Product Declaration EPD-JDL-20200260-IBB1-DE
Products
steel, batch/hot-dip galvanized
| Products | L length | BP profile width | HP profile height | t Material strength | A cross section area | W Weight per storage unit | bookmark |
|---|---|---|---|---|---|---|---|
| LSK3817 FV-6000 | 6000 mm | 38 mm | 17 mm | 3 mm | 1,97 cm² | 10,680 kg |
Stainless steel, according to ASTM 316 Ti / AISI 316 L, BS 320S17 / BS 316S11
| Products | L length | BP profile width | HP profile height | t Material strength | A cross section area | W Weight per storage unit | bookmark |
|---|---|---|---|---|---|---|---|
| LSK3817 A4-6000 | 6000 mm | 38 mm | 17 mm | 3 mm | 1,97 cm² | 11,046 kg |
