The rungs STLS can be installed during the installation of the vertical ladder and bolted to the side rail. They are suitable for STU 50 vertical ladders and are 203 to 793 mm wide corresponding to the vertical ladder width. We provide components in various materials and surface finishes to ensure that the corrosion requirements are met for all sorts of applications.
data sheetTender text
You can find the appropriate tender text for this product on these portals:
Products
steel, continously hot galvanized/Sendzimir process
| Products | L length | B width | H height | W Weight per storage unit | incl. show all inclusive accessoires | bookmark |
|---|---|---|---|---|---|---|
| STLS 02S | 203 mm | 40 mm | 22 mm | 0,237 kg | ||
| STLS 03S | 293 mm | 40 mm | 22 mm | 0,355 kg | ||
| STLS 04S | 393 mm | 40 mm | 22 mm | 0,468 kg | ||
| STLS 05S | 493 mm | 40 mm | 22 mm | 0,577 kg | ||
| STLS 06S | 593 mm | 40 mm | 22 mm | 0,704 kg | ||
| STLS 07S | 693 mm | 40 mm | 22 mm | 0,894 kg | ||
| STLS 08S | 793 mm | 40 mm | 22 mm | 0,903 kg |
steel, batch/hot-dip galvanized
| Products | L length | B width | H height | W Weight per storage unit | incl. show all inclusive accessoires | bookmark |
|---|---|---|---|---|---|---|
| STLS 02F | 40 mm | 203 mm | 22 mm | 0,270 kg | ||
| STLS 03F | 40 mm | 293 mm | 22 mm | 0,379 kg | ||
| STLS 04F | 40 mm | 393 mm | 22 mm | 0,509 kg | ||
| STLS 05F | 40 mm | 493 mm | 22 mm | 0,656 kg | ||
| STLS 06F | 40 mm | 593 mm | 22 mm | 0,754 kg | ||
| STLS 07F | 40 mm | 693 mm | 22 mm | 0,996 kg | ||
| STLS 08F | 40 mm | 793 mm | 22 mm | 1,116 kg |
