Cover for wide-span cable ladder bend. With additional turning bolts.
data sheet
Continously hot galvanized (Sendzimir process) (DIN EN 10346)
| width | length | t material thickness | weight | ||
|---|---|---|---|---|---|
| WLBDR 20S | 242 mm | 641 mm | 0,75 mm | 1,24 kg | |
| WLBDR 30S | 342 mm | 741 mm | 1,00 mm | 2,46 kg | |
| WLBDR 40S | 442 mm | 841 mm | 1,00 mm | 3,42 kg | |
| WLBDR 50S | 542 mm | 941 mm | 1,25 mm | 5,62 kg | |
| WLBDR 60S | 642 mm | 1041 mm | 1,25 mm | 7,15 kg |
Hot-dip galvanized, according to BS 729 (DIN EN ISO 1461)
| width | length | t material thickness | weight | ||
|---|---|---|---|---|---|
| WLBDR 20F | 242 mm | 641 mm | 0,75 mm | 1,32 kg | |
| WLBDR 30F | 342 mm | 741 mm | 1,00 mm | 2,63 kg | |
| WLBDR 40F | 442 mm | 841 mm | 1,00 mm | 3,66 kg | |
| WLBDR 50F | 542 mm | 941 mm | 1,25 mm | 6,01 kg | |
| WLBDR 60F | 642 mm | 1041 mm | 1,25 mm | 7,65 kg |
